Brake/Clutch Fluid Maintenance

Brake/clutch fluid





Change fluid according to the interval in the service programme.

Grade: to DOT 4 specification.

Never use brake fluid which has been stored in an open container.

Important: See Service Manual 5:1, in which special safety procedures are described.





Fill out the "BRAKE FLUID exchanged" label, part number 30 70 17. Affix it in a suitable place on the front structure beside the brake fluid reservoir.

Brake hoses and brake lines

Check for leakage, inspect mounting points and general condition.
