No Sound. SID Displays Audio Information

No Sound. The SID Unit Displays Audio Information







Fault symptoms
No sound.

SID shows audio information.

Probable cause of fault
Blown fuse for the amplifier.

Checking the wiring harness
Jiggle the wiring harness at several points and in different directions to check if there are intermittent breaks and short-circuits in the leads. Observe the multimeter, test lamp or diagnostic instrument during the test.
