CD Changer Theft Protection Faulty

CD Changer Theft Protection Faulty









Fault symptoms
The following information is shown on SID:
^ CDC LOCKED (CD changer)
^ CDC CODE (CD changer)

No sound at all.

Conditions

B2670
^ The CD changer receives theft protection information over the bus from DICE and TWICE. If the theft protection information is incorrect, CDC LOCKED or CDC CODE will be shown.
^ If the theft protection for the CD changer (marriage or divorce) is programmed without DICE and TWICE on the bus, CDC LOCKED or CDC CODE will be displayed.

Diagnostic help
See Changing radio system
