Horn, High Tone



Horn, High Tone

To remove
1. Raise the car.
2. Remove the bolt.







3. Lower the spoiler shield hatch.
4. Unplug the horn connector.
5. Remove the horn.

To fit
1. Plug in the horn connector.







2. Fit the horn.
3. Close the spoiler shield hatch.
4. Fit the screw.
5. Lower the car to the floor.
