P2127

P2127 00

Pedal Position Sensor Circuit 2. Short to Ground/Open Circuit.







Fault symptom
- Check Engine
- Limp home
- Messages shown in SID.

On-board diagnosis

Type of diagnosis:
- Continuous

Enable criteria:
- When the ECM is awake, diagnosis is active (even with the ignition off).

Fault criteria:
- When input voltage is below 0.13 V.

Dependent:
- None

System reaction to a fault:
- Limp home

OK report:
- Fault criterion not fulfilled and vehicle speed over 0 km/h for more than 60 s.

Fault handling:
Type III
(See section Fault handling III, "Other emission-related components and functions" for more information.)

Checking the wiring harness
- Move the wiring harness at several spots and in several directions to reveal intermittent breaks and short-circuits. Check switches, connectors and crimp connections for oxidation, retracted pins and pin clamping force.

Diagnostic help

Diagnosis regards:
- Electrical fault in connecting leads or component.

Functions in the diagnostic tool related to the fault:

Test value:
- Pedal Position Sensor 2
(See also description of readings/activations in diagnostic tool)
