P0730

P0730 60

Gear Function. Mechanical Fault.







Fault symptom
- Messages shown in SID.
- Poor shifting quality.

On-board diagnosis

Type of diagnosis:
- Continuous

Enable criteria:
- Engine running and not in limp home mode.

Exceptions:
- Output speed < 500 rpm.

Fault criteria:
- Gears 4 and 5 not working but upshift to 3rd gear possible.

System reaction to a fault:
- Messages shown in SID.
- Only gears 1 -3 working.

Diagnostic help

Diagnosis regards:
- Locating a mechanical fault.
