P0705

P0705 08

Transmission Range Switch. Input Incorrect.







Fault symptom
- Messages shown in SID.
- Poor shifting quality.

On-board diagnosis

Type of diagnosis:
- Continuous

Enable criteria:
- Engine running.

Fault criteria:
- Combination of gear position sensor inputs to TCM not permitted.

System reaction to a fault:
- TCM in Limp Home.
- Limited shifting functions.

Checking the wiring harness
- Move the wiring harness at several spots and in several directions to reveal intermittent breaks and short-circuits. Check switches, connectors and crimp connections for oxidation, retracted pins and pin clamping force.

Diagnostic help

Diagnosis regards:
- Locating a mechanical fault.

Functions in the diagnostic tool related to the fault:

Test value:
- Gear Selector Position
(See also description of readings/activations in diagnostic tool)
