B3935

B3935 00

Malfunctioning Transponder Detected at Key in







Fault symptom
- Messages shown in SID.
- Ignition cannot be switched off.

On-board diagnosis

Type of diagnosis:
- Diagnostics is carried out each time the key is inserted in the ignition switch.

Enable criteria:
- Key in ignition switch.

Fault criteria:
- Incorrect transponder identification.

System reaction to a fault:
- None

Diagnostic help
- A trouble code is generated if a key from another car is inserted in the ignition switch.

Diagnostic help

Diagnosis regards:
- Electrical fault in connecting leads or component.

Functions in the diagnostic tool related to the fault:

See Reading:
- Transponder Fixcode OK
- Transponder Encryption ID OK
(See also description of readings/activations in diagnostic tool)
