B3056

B3056 00

No Transponders Learned to CIM







Fault symptom
- Cannot turn key.
- Engine does not start.
- Messages shown in SID.

On-board diagnosis

Type of diagnosis:
- Continuous

Enable criteria:
- Diagnostics runs when key is inserted.

Fault criteria:
- No transponders programmed in CIM.

System reaction to a fault:
- None

Diagnostic help
- See "After fitting a control module" under fault diagnosis, general.

Diagnostic help

Functions in the diagnostic tool related to the fault:
- See menu "All - Add/Remove"
