B3055

B3055 00

No Transponder Detected at Key in







Fault symptom
- Messages shown in SID.
- Key cannot be turned in ignition switch.
- Engine does not start.

On-board diagnosis

Type of diagnosis:
- Diagnostics is carried out each time the key is inserted in the ignition switch.

Enable criteria:
- Key in ignition switch.

Fault criteria:
- No transponder detected.

System reaction to a fault:
- None

Diagnostic help
- The DTC is generated if an object is forced into the ignition lock.

Diagnostic help

Functions in the diagnostic tool related to the fault:

Test value:
- Check Ignition Key Status
- See menu "All - Add/Remove"
