B1310 59

B1310 59

Soft Top Closed, Position Sensor, Timeout







Fault symptom
- The soft top stops somewhere in its cycle.
- Messages shown in SID.

On-board diagnosis

Type of diagnosis:
- Continuous

Enable criteria:
- Ignition ON.
- Soft top opening/closing activated

Fault criteria:
- The position sensor assumes impermissible position while soft top is in operation

Diagnostic help

Diagnosis regards:
- Check that the bow is locked within the specified time

Functions in the diagnostic tool related to the fault:

Test value:
- Main Cylinder Up
(See also description of readings/activations in diagnostic tool)
