B1300 59

B1300 59

1st Bow Latched, Position Sensor, Timeout







Fault symptom
- Messages shown in SID.
- The soft top stops somewhere in its cycle.

On-board diagnosis

Type of diagnosis:
- Continuous

Enable criteria:
- Ignition ON.
- Soft top opening/closing activated

Fault criteria:
- Too long before position sensor changes status

Diagnostic help
- Check that no objects hinder soft top operation and movement and that the soft top mechanism does not jam.

Diagnostic help

Diagnosis regards:
- Check that the bow is locked within the specified time

Functions in the diagnostic tool related to the fault:

Test value:
- 1st Bow Locked
(See also description of readings/activations in diagnostic tool)
