B1016 00 - 04

B1016 00

Control Module not Added







Fault symptom
- No function

On-board diagnosis

Type of diagnosis:
- For +30 reset and after programming.

Enable criteria:
- Ignition ON.

Fault criteria:
- Control module was not added.

Diagnostic help
- Control module was not added.
- See "Procedure after fitting the control module"
- Check that the following MIs/Campaigns have been carried out before starting fault diagnosis:

US Market
- MI No. 391-2394 - Customer Satisfaction Campaign 15421 - Update of OnStar system.
- MI No. 391-2409 - Customer Satisfaction Campaign 15424 - Update of OnStar system.

CA Market
- MI No. 391-2410 - Customer Satisfaction Campaign 15421 - Update of OnStar system.
- MI No. 391-2408 - Customer Satisfaction Campaign 15424 - Update of OnStar system.

Diagnostic help

Functions in the diagnostic tool related to the fault:
- See menu "All - Add/Remove"
