B1016 00 - 03

B1016 00

Control Module Not Added







On-board diagnosis

Type of diagnosis:
- Diagnostics is carried out after "Reset" and after the VIN has been programmed.

Enable criteria:
- Diagnostics runs when key is inserted.

Fault criteria:
- VIN not programmed.

System reaction to a fault:
- None

Diagnostic help
- See "After fitting a control module" under fault diagnosis, general.

Diagnostic help

Diagnosis regards:
- Checking if the VIN is programmed in the control module.

Functions in the diagnostic tool related to the fault:
- See menu "All - Add/Remove"
