B0488

B0488 00

Overheat Counter Overrun System locked







Fault symptom
- Poor cabin heating
- Heater does not start.

On-board diagnosis

Type of diagnosis:
- Continuous

Enable criteria:
- Ignition ON.
- Heater not in rest mode.

Fault criteria:
- More than 10 overheatings.

System reaction to a fault:
- Heater does not start.

Checking the wiring harness
- Move the wiring harness at several spots and in several directions to reveal intermittent breaks and short-circuits. Check switches, connectors and crimp connections for oxidation, retracted pins and pin clamping force.

Diagnostic help

Functions in the diagnostic tool related to the fault:

Test value:
- Disabled. Too Many Overheatings
(See also description of readings/activations in diagnostic tool)
