ABS Without TCS or ESP

C2415 Solenoid Valves Rear Left. Incorrect





Fault symptoms
ABS warning lamp on. ABS not functioning.

Conditions
The valves are monitored continuously for circuit continuity and short-circuiting.
The valve test starts when the ignition is switched ON and road speed is above 6 km/h.

Diagnostic help
The solenoid valves can be activated using the diagnostic tool.
- Select "Activate".
- Select "Valves"

Select the valve from the submenu. The selected valve will be activated at a frequency of 1 Hz for about 30 s.

Change the control module.
