B0080

B0080

B0080 Driver Side Airbag Sensor, internal fault.










Fault symptoms
Airbag warning lamp on.

Conditions
Ignition ON

Fault criteria
Upon ignition, the side impact sensor carries out a self-test. If an internal fault is detected, the side impact sensor sends a message to the control module and DTC B0080 is set.

System reaction to a fault
The control module ignores all signals from the impact sensor as long as the fault is present.

Diagnostic help
Fault Diagnosis Procedure
