Home >> Saab >> 2004 >> 9-3 Linear (9440) L4-2.0L Turbo (2.0t) >> Repair and Diagnosis >> Wiper and Washer Systems >> Relays and Modules - Wiper and Washer Systems >> Wiper Relay >> Diagrams >> Windscreen Wiper Relay (83)

Windscreen Wiper Relay (83)



Location: in the transmission range switch on transmission


Windscreen Wiper Relay (83):
