P2187

P2187 00

Long Term Fuel Trim Additive. Max Value, Air/Fuel Too Lean.







Fault symptom
Check Engine (OBD II, EOBD).
The engine may stop after starting, run unevenly and misfire or run at high rpm.

On-board diagnosis

Type of diagnosis:
Continuous

Enable criteria:
The engine has started and lambda control is active.
An additive adaptation is carried out.
NONE of the following DTCs must be detected: P0444, P0445

Fault criteria:
Additive adaptation is +4.00 mg/c.

Dependent
P0131, P0132, P0134

System reaction to a fault:
None

OK report:
Provided that the fault criteria are not fulfilled during the operating cycle, there is an OK report upon ignition shut-off before the engine stops. Two types of OK reports are possible: Type 1: If there is already a DTC stored for the diagnosis and operating conditions were the same (coolant temperature over or under 71 degree C, engine speed 375 rpm and load 10%). Type 2: If there is no DTC stored for the diagnosis or if operating conditions were not the same.

Fault handling:
Type II
(See Description of On-Board Diagnostics/Fault handling II, "Emission-related misfiring or fault in fuel system" for more information.)

Diagnostic help

Diagnosis regards:
Checking air/fuel ratio. With this DTC, the engine will be getting too much air or too little fuel.

Functions in the diagnostic tool related to the fault:
Test value:
- O2S 1
- Additive Adaptation
- Short Term Fuel Trim
- Purge Adaptation
- Airmass Deviation from Calculated
