P1743 60 (TCM - Trans Control Module)

P1743 60

Lock-Up. Mechanical Fault.







Fault symptom
Messages shown in SID.

On-board diagnosis

Type of diagnosis:
Continuous

Enable criteria:
Engine running and not in limp home mode.

Fault criteria:
TCM registers rapid speed changes on the output shaft or TCM registers a difference greater than 100 rpm between input shaft speed and engine rpm.

System reaction to a fault:
Excluded Lock-Up function.
Poor shifting quality.

Diagnostic help

Diagnosis regards:
Locating a mechanical fault.
