P0780

P0780 60

Shifting Time. Mechanical Fault.







Fault symptom
Messages shown in SID.

On-board diagnosis

Type of diagnosis:
During shifting.

Enable criteria:
Engine running and not in limp home mode.
Exceptions:
- Oil temperature less than 60 degree C
- Selector lever not in position D.
The following diagnostic trouble codes may not be generated:
- Engine RPM
- Engine Torque
- Gearbox Input RPM
- Gearbox Fluid Temperature

Fault criteria:
The control unit checks the shifting continuously and generates a trouble code if shift-up or shift-down is not performed correctly.

System reaction to a fault:
Limp home

Diagnostic help

Diagnosis regards:
Locating a mechanical fault.
