P0730

P0730 60

Gear Function. Mechanical Fault.







Fault symptom
Messages shown in SID.
Poor shifting quality.

On-board diagnosis

Type of diagnosis:
Continuous

Enable criteria:
Engine running and not in limp home mode.
Exceptions:
- Output speed less than 500 rpm.

Fault criteria:
Gears 4 and 5 not working but upshift to 3rd gear possible.

Dependent

System reaction to a fault:
Messages shown in SID.
Only gears 1 -3 working.

Diagnostic help

Diagnosis regards:
Locating a mechanical fault.
