P0245

P0245 00

Boost Pressure Control Valve Circuit. Open/Short to Ground.







Fault symptom
CHECK Engine
Limp home
Any noise upon release of accelerator.

On-board diagnosis

Type of diagnosis:
Continuous

Enable criteria:
Engine running.

Fault criteria:
Voltage on the output is below 2.0 V for more than 1 s.

Dependent:
None

System reaction to a fault:
Torque limited to max. 170 Nm.

OK report:
When fault criteria NOT fulfilled for 2 s.

Fault handling:
Type III
(See Description of On-Board Diagnostics/Fault handling III, "Other emission-related components and functions" for more information.)

Checking the wiring harness
Move the wiring harness at several spots and in several directions to reveal intermittent breaks and short circuits. Check switches, connectors and crimp connections for oxidation, retracted pins and pin clamping force.

Diagnostic help

Diagnosis regards:
Electrical Fault in connecting leads or component.

Functions in the diagnostic tool related to the fault:
Activation:
- Charge Air Control Valve
