C0855

C0855 03
+X Circuit, Open/Short to Ground





Fault symptom
Messages shown in SID.
Steering column lock not working.
On-board diagnosis
Type of diagnosis:
Continuous
Fault criteria:
Battery voltage is below 9.5 V for 0.5 s.
System reaction to a fault:
Steering column lock deactivated.
Checking the wiring harness
Move the wiring harness at several spots and in several directions to reveal intermittent breaks and short-circuits. Check switches, connectors and crimp connections for oxidation, retracted pins and pin clamping force.
Diagnostic help
Diagnosis regards:
Electrical fault in connecting leads or component.
