C0460 11
C0460 11Steering angle sensor. Faulty signal
Fault symptom
ESP warning lamp on.
Messages shown in SID.
On-board diagnosis
Type of diagnosis:
Continuous
Enable criteria:
Test 1
^ Ignition ON.
Test 2
^ Engine running.
^ Vehicle speed over 15 km/h
Test 3
^ Ignition ON.
Test 4
^ Engine running.
^ Vehicle speed over 15 km/h
^ Diagnostics runs when there is a speed difference between the wheel sensors.
Fault criteria:
Test 1
^ Steering wheel angle sensor exceeds normal value for normal driving (300 degrees/s)
Test 2
^ The calculated steering angle compensation exceeds 18 degrees.
Test 3
^ Steering angle exceeds +/- 720 degrees.
Test 4
^ Value of steering angle sensor is stuck.
System reaction to a fault:
No ESP function
Diagnostic help
The DTC is generated if the wheels are out of alignment.
Diagnostic help
Diagnosis regards:
Electrical fault in connecting leads or component.
Functions in the diagnostic tool related to the fault:
Test value:
Steering Angle
(See also description of readings/activations in diagnostic tool)
