B1023 63 (ICM3 - Infotainment Control Module 3RD Level)

B1023 63

SID, button stuck






On-board diagnosis
Type of diagnosis:
Continuous

Enable criteria:
Ignition ON.

System reaction to a fault:
None

Checking the wiring harness
Move the wiring harness at several spots and in several directions to reveal intermittent breaks and short-circuits. Check switches, connectors and crimp connections for oxidation, retracted pins and pin clamping force.

Diagnostic help
Diagnosis regards:
Electrical fault in connecting leads or component.
