Reversing Lights Malfunctioning

Reversing Lights Malfunctioning

Fault symptoms
Reversing lights malfunctioning










Diagnostic help
Check fuse 31 in the cabin.

Check the wiring harness
Jiggle the wiring harness in several places and in various directions to detect intermittent open circuits and short circuits in the wiring harness. Watch the multimeter, diagnostic tool and test lamp during the check.
