ABS Warning Lamp Constantly On

ABS Warning Lamp Constantly On






Fault symptoms
ABS warning lamp constantly on.

No DTCs are set.

Conditions
Bus communication must be in working order. See System overview, refer to Powertrain Management.

Diagnostic help
The ABS warning lamp can be activated with the diagnostic tool.
- Select "Activate"
- Select "ABS lamp"
