The ABS Lamp Is Constantly On

The ABS Lamp Is Constantly On.






Fault symptoms
The ABS lamp is constantly on.
No DTCs generated.

Conditions
^ Circuit between pin 21 on the ABS control module and pin 10 on the MIU (K20) shorting to ground.

^ Short-circuit contact strip in connector defective.

Diagnostic help
The ABS warning lamp can be activated using the diagnostic tool.
- Select "Activate"
- Select "ABS Lamp"
