Antenna Unit, Immobilization

Antenna Unit, Immobilization

To remove







1. Loosen the antenna unit by turning it clockwise.
2. Lift the unit and disconnect the electrical connector.

To fit







1. Fit the connector on the antenna unit.
2. Fit the antenna unit.
