TC/ABS 5.3

DTC C2465 Pump Motor, Defective






Fault symptoms
Warning lamps for ABS and brakes are on as also is the central warning lamp.

TCS OFF warning lamp is on.

No ABS or TCS function.

Conditions
The pump motor is continuously monitored for open/short circuits. Pump motor test is conducted with ignition ON and wheel speed above 6 km/h (3.7 mph).

Diagnostic help
The pump motor can be activated using the diagnostic tool.
- Select "Activate"
- Select "Pump motor".

If the TC/ABS control module is not connected to ground (pin 16), diagnostic trouble code C2465 will be set.
