Home >> Saab >> 2002 >> 9-5 Linear Sport Wagon (9600) L4-2.3L Turbo (B235) >> Repair and Diagnosis >> Body and Frame >> Locks >> Locations >> Ground Locations >> Grounding Point G24

Grounding Point G24




Grounding Point G24












Location: On the seat member under the right-hand seat.


Part 1:






Part 2:






Part 3:
