TSC Lamp Does Not Come On

TSC lamp does not come on






Fault symptoms
Lamp test is conducted when ignition turned on. TCS indicator lamp should be on for about 3 seconds. TCS indicator lamp does not come on.

Conditions
Bus communication must be in working order. See System overview, refer to Powertrain Management.

Diagnostic help
The TCS lamp can be activated with the diagnostic tool.
- Select "Activate"
- Select "TCS Lamp"
