Switches In the Dashboard

Switches In the Dashboard

To remove


NOTE: Be careful not to damage the dashboard







1. Extract the switch using two screwdrivers. (Hazard flashers) The switch should be in the active position before extracting it.
2. Unplug the connector.

To fit







1. Replug the connector.
2. Push the switch into position.
