Switch, Cruise Control



To remove

1 Turn the steering wheel and remove the two screws securing the steering column cowling





2 Remove the lower screw.
3 Remove the cowling. Mind the cowl hooks.
4 Unplug the connector.
5 Remove the stalk switch.

To fit





1 Position the stalk switch.
2 Spray the connector with Kontakt 61 contact cleaner (part no.30 04 520). Plug in the connector.
3 Fit the cowling. Mind the cowl hooks.
4 Tighten the lower screw.
5 Turn the steering wheel and fit the two screws in the steering column cowling.
