Heated Element, Mirror

Electrically Heated Rear Window and Door Mirrors

Components
8 Main beam relay; on main relay board in the engine bay.
8a Dipswitch relay; on main relay board in the engine bay,
10 Lights switch; on dashboard between steering wheel and driver's door.
11FL Main beam lamp; in LH headlamp.
211FR Main beam lamp; in RH headlamp.
12FL Dipped beam lamp; in LH headlamp.
12FR Dipped beam lamp; in RH headlamp.
213FL Parking light lamp; in LH headlamp.
13FR Parking light lamp; in RH headlamp.
13RL Parking light lamp; in rear LH light cluster.
13RR Parking light lamp; in rear RH light cluster.
14RL Rear light lamp; in rear LH light cluster.
14RR Rear light lamp; in rear RH light cluster.
15 Licence plate light; on boot lid/tailgate.
16 Rheostat for instrument lighting; in lights switch panel between steering wheel and driver's door.
19 Glove box light; in glove box side wall.
22a Main fuse board; on side of dashboard by driver's door.
24 Direction indicator stalk switch; on left-hand side of steering column.
25 Hazard flasher switch; by centre panel outlet on dashboard.
27FL Direction indicator lamp; in front LH light cluster.
27FR Direction indicator lamp; in front RH light cluster.
27RL Direction indicator lamp; in rear LH light cluster.
27RR Direction indicator lamp; in rear RH light cluster.
29 Brake light switch; on the pedal assembly.
30RC High mounted brake light; in roof above rear window.
30RL Bright light lamp; in rear LH light cluster.
30RR Bright light lamp; in rear RH light cluster.
31 Reversing light switch; on the gearbox.
32HL Reversing light lamp; in LH light on boot lid/tailgate.
32HR Reversing light lamp; in RH light on boot lid/tailgate.
33HL Rear fog light lamp; in LH light on boot lid/tailgate.
33HR Rear fog light lamp; in RH light on boot lid/tailgate.
35 Ventilation fan switch; on MCC control panel.
36 Ventilation fan motor; in upper section of climate housing.
37LH Radiator fan motor; on LH side of radiator.
37RH Radiator fan motor; on RH side of radiator.
38 Air recirculation flap; on console next to fan motor on passenger side.
50C Centre dome lamp; in centre of roof.
50F Front dome lamp; in roof above windscreen.
53 Cabin lighting switch; in front dome lamp roof console.
55 Luggage compartment lighting; under rear shelf.
56 Luggage compartment light switch; by boot lid/tailgate lock.
61 Windscreen wiper stalk switch; on RH side of steering column.
62F Windscreen wiper motor; LHD: in engine bay on RH side of bulkhead partition. RHD: in engine bay on LH side of bulkhead partition.
63a Washer motor; on washer fluid reservoir in LH wheel housing.
63b Washer motor; on washer fluid reservoir in LH wheel housing.
66FL Headlamp wiper motor; behind LH headlamp.
66FR Headlamp wiper motor; behind RH headlamp.
81 Relay, 2-speed radiator fan, high-speed, alternatively Relay, high-speed LH fan; on main relay board in engine bay.
83 Intermittent windscreen wiper relay; on main relay board in engine bay.
85FL Fog light lamp; in LH side of spoiler.
85FR Fog light lamp; in RH side of spoiler.
88 Fog lights switch; in 3-switch bank between steering wheel and driver's door.
89LH Side direction indicators; on LH front wing.
89RH Side direction indicators; on RH front wing.
91 Gear position indicator lighting; by gear lever.
107 Fog light relay; on main relay board in engine bay.
113 Relay, electrically heated rear window on main relay board in dashboard.
115 Electrically heated rear window; in rear window.
116 Rear window heater switch; on MCC control panel.
118FL Corner light lamp; in LH fog light.
118FR Corner light lamp; in RH fog light.
119FL Side reversing light lamp; in front LH light cluster.
119FR Side reversing light lamp; in front RH light cluster.
143 Air recirculation switch; on MCC control panel.
148F Front ashtray/cigarette lighter lighting; by cigarette lighter.
148R Rear ashtray/cigarette lighter lighting; by cigarette lighter.
150b Fan control switch for NC shut-off; or MCC control panel.
154 Control panel lighting; on MCC control panel.
155 Relay, 2-speed radiator fan, low-speed, alternatively Relay, low-speed 2 radiator fans; on main relay board in engine bay.
156 A/C compressor relay; on main relay board in engine bay.
161 Rear fog lights switch; on lights switch panel between steering wheel and driver's door.
169 A/C switch; on MCC control panel.
170 A/C compressor; on right-hand side of engine.
202 Coolant temperature sensor; on LH side of cylinder head.
207D Heater element, driver's door mirror; on back of mirror glass.
207P Heater element, passenger door mirror; on back of mirror glass.
209D Courtesy light in driver's door; on bottom edge of door trim.
209P Courtesy light in passenger door; on bottom edge of door trim.
209RL Courtesy light in LH rear door; on bottom edge of door trim.
209RR Courtesy light in RH rear door; on bottom edge of door trim.
215 Dipswitch; on RH side of steering column.
216 ACC control module; in the centre of the dashboard.
220 Ventilation fan control unit; on driver's side of climate housing by the bulkhead partition.
221a Air distribution flap motor for defrost/panel/floor; on side of climate housing above passenger floor duct outlet.
221b Air distribution flap motor for LH/RH adjustment; on side of climate housing above driver's floor duct outlet.
222LH Mixed-air flap motor; on RH side of climate housing between floor duct outlet and radio box.
222RH Mixed-air flap motor; on LH side of climate housing between floor duct outlet and radio box.
225FC Front reading lamp; in front dome lamp roof console.
225RL Rear reading lamp; in centre dome lamp roof console.
225RR Rear RH reading lamp; in centre dome lamp roof console.
228b Filament monitor for front lamps; on main relay board in engine bay.
234FL Side marker lights; in front LH light cluster.
(US)
234FR Side marker lights; in front RH light cluster.
(US)
239 Transmission range switch 2, automatic (31,77); on gear box.
252LH LH seat heating pad switch; on bottom centre of dashboard.
252RH RH seat heating pad switch; on bottom centre of dashboard.
258 Tow bar contact; in luggage compartment on RH side of rear plate.
267a Radio connector A; grey connector behind radio box.
342a Main fuse board; behind battery.
359LH LH vanity mirror lighting; in sun visor.
359RH RH vanity mirror lighting; in sun visor.
367 Resistor for 2-speed radiator fan; on radiator fan cowling.
375 Mobile telephone connector; by radio console.
388 Switch for boot lid/tailgate; in driver's door.
396 Radiator fan relay high-Speed RH fan; on main relay board in engine bay.
405 Reversing light relay; on main relay board in dashboard.
430 Saab Trionic engine control module; in assembly (cabin side) in front of windscreen on passenger side.
449 Switch for TCS OFF: on dashboard between steering wheel and centre panel outlet.
503 Switch for rear seat heating; on rear of centre console between the seats.
504 Control panel for heating and ventilation; in centre of dashboard.
506 WINTER switch.
540 Main instrument display panel; on dashboard in front of driver.
541 SID; centre of dashboard.
581 Heat exchanger solenoid valve; on console by shut-off valve.
613FL Front LH floor lighting; on the floor farthest in under the dashboard.
61 3FR Front RH floor lighting; on the floor farthest in under the dashboard.
613RL Rear LH floor lighting; in floor mat under LH seat.
613RR Rear RH floor lighting; in floor mat under RH seat.
615LH Switch for LH seat ventilation; bottom centre of dashboard.
615RH Switch for RH seat ventilation; bottom centre of dashboard.
618 Intermittent wiper rheostat; integrated in windscreen wiper stalk switch on RH side of steering column.
620 A/C pressure sensor; bottom RH side of evaporator.
621 A/C evaporator temperature sensor; below connector console on passenger side of climate housing.
624 Radio aerial amplifier; on right-hand C pillar.
628 DICE control module; on main relay board in dashboard.
632 TWICE control module; under LH seat.
644 Aerial ground filter; on left-hand C pillar.

6-pin connector
H6-4 By gear lever console.

10-pin connectors
H10-1 Grey connector in roof by front dome light console.
H10-2 Between rear LH light cluster and boot lid/tailgate.
H10-5 Black connector on front of climate housing facing centre console.
H10-6 Grey connector on front of climate housing facing centre console.
H10-7 Under battery tray.

16-pin connector
H16-1 In left-hand B pillar.
H16-2 In right-hand B pillar.
H16-3 In cable conduit in front of airbag control module.

42-pin connector
H42-1 On front edge of driver's door.
(LHD)
H42-2 On front edge of passenger door.
(LHD)
H42-3 On front edge of driver's door.
(RHD)
H42-4 On front edge of passenger door.
(RHD)

43-pin connector
H43-1 White connector in connector console under left-hand A pillar.
H43-2 Blue connector in connector console under left-hand A pillar.

70-pin connector
H70-1 In centre of bulkhead partition (engine bay side).

80-pin connector
H80-1 In connector console under left-hand A pillar.

Crimped connections
J1 Front harness; approx. 150 mm from grounding point G31.
J2 Front harness; approx. 50 mm from grounding point G30 branching point towards ABS.
J3 Front harness; approx. 100 mm from grounding point G30 branching point towards ABS.
J6 Front harness; in main fuse box approx. 20 mm from branching point towards relays.
J7 Front harness; approx. 800 mm from ABS control module branching point towards grounding point G30.
J17 Engine harness; approx. 70 mm from Trionic control module connector cable tie.
J34 Engine harness; 100 mm from Trionic control
4-cyl module connector.
LHD
J34 Engine harness; 100 mm from Trionic control
4-cyl module connector.
RHD
J35 Engine harness; 100 mm from Trionic control
4-cyl module connector.
LHD
J36 Engine harness; 100 mm from Trionic control
4-cyl module connector.
RHD
J36 Engine harness; 100 mm from connector
4-cyl H70-1.
LHD
J36 Engine harness; 100 mm from connector
4-cyl H70-1.
RHD
J37 Engine harness; 100 mm from connector
4-cyl H70-1.
LHD
J37 Engine harness; 100 mm from connector
4-cyl H70-1.
RHD
J38 LHD Approx. 225 mm from grounding point G41P branching point towards ignition switch. (Instrument harness).
J39 Approx. 275 mm from SID branching point
RHD towards ignition switch. (Instrument harness).
J40 LHD Instrument harness; approx. 100 mm from DICE branching point towards connector H43-1.
J40 Instrument harness; approx. 40 mm from
RHD DICE branching point towards engine bay grommet.
J41 LHD Instrument harness; approx. 20 mm from SID branching point towards MIU.
J41 Instrument harness; approx. 90 mm from
RHD warning switch branching point towards MIU.
J42 LHD instrument harness; approx. 50 mm from grounding point G40 branching point towards lights switch.
J42 Instrument harness; approx. 200 mm from
RHD lights switch branching point towards grounding point G42.
J44 LHD Instrument harness; approx. 140 mm from SID branching point towards grounding point G42.
J44 Instrument harness; approx. 170 mm from
RHD SID branching point towards ignition switch.
J45 LHD Instrument harness; approx. 40 mm from glove box branching point towards M1U.
J45 Instrument harness; approx. 320 mm from
RHD glove box light branching point towards MIU.
J46 LHD Instrument harness; approx. 80 mm from grounding point G42 branching point towards DICE.
J46 Instrument harness; approx. 30 mm from
RHD grounding point G42 branching point towards SID.
J47 LHD Instrument harness; approx. 110 mm from MIU (12-pin connector) branching point towards data link connector.
J47 Instrument harness; approx. 150 mm from
RHD data link connector branching point towards data link connector.
J48 LHD Instrument harness; approx. 50 mm from DICE branching point towards connector H43-1.
J48 Instrument harness; approx. 50 mm from
RHD DICE branching point towards main relay board.
J55 LHD Instrument harness; approx. 125 mm from DICE branching point towards connector H43-1.
J55 Instrument harness; approx. 130 mm from
RHD grounding point G42 branching point towards DICE.
J58 LHD Instrument harness; approx. 50 mm from MIU (12-pin connector) branching point towards data link connector.
J58 Instrument harness: approx. 100 mm from
RHD MIU (12-pin connector) branching point towards heater housing.
J62 LHD Instrument harness; approx. 400 mm from windscreen wiper stalk switch connector.
J62 Instrument harness; approx. 280 mm from RHD windscreen wiper stalk switch connector.
J63 LHD Instrument harness; approx. 10 mm from DICE branching point towards switches.
J63 Instrument harness; approx. 210 mm from
RHD MIU (20-pin connector) branching point towards DICE.
J65 LHD Instrument harness; approx. 40 mm from MIU (20-pin connector) branching point towards its 12-pin connector.
J65 Instrument harness; approx. 210 mm from
RHD MIU (12-pin connector) branching point towards heater housing.
J66 LHD Instrument harness; approx. 60 mm from DICE branching point towards steering wheel switches.
J66 Instrument harness; approx. 100 mm from
RHD MIU (20-pin connector) branching point towards DICE.
J67 LHD Instrument harness; approx. 30 mm from grounding point G41S branching point towards radio connector.
J67 Instrument harness; in branching point RHD towards grounding point G41S.
J70 Instrument harness; approx. 30 mm from radio connector.
J71 Instrument harness; approx. 30 mm from radio connector.
J72 Instrument harness; approx. 50 mm from MIU 12-pin connector.
J73 Instrument harness; approx. 50 mm from MIU 12-pin connector.
J74 Instrument harness; by ACC/MCC control module connector cable tie.
J75 Instrument harness; by ACC/MCC control module connector cable tie.
J76 Instrument harness; approx. 50 mm from SID connector.
J77 Instrument harness; approx. 50 mm from SID connector.
J84 Instrument harness; by connector H70-1 rear cable tie.
J85 Instrument harness; by connector H70-1 rear cable tie.
J86 Instrument harness; approx. 50 mm from MIU 12-pin connector.
J87 Instrument harness; approx. 50 mm from MIU 12-pin connector.
J88 LHD Instrument harness; approx. 10 mm from grounding point G41S branching point towards SID.
J88 Instrument harness; approx. 90 mm from
RHD hazard flasher switch branching point towards MIU.
J90 Rear harness; approx. 50 mm from grounding point G33 branching point towards LH side direction indicator.
J91 Rear harness; approx. 30 mm from grounding point G3 branching point towards rear light cluster.
J93 Rear harness; approx. 20 mm from rear end of rear RH door floor console towards grounding point G5.
J95 Rear harness; approx. 150 mm from RH seat branching point towards rear RH door.
J96 Rear harness; approx. 375 mm from connector H43-2 branching point towards rear LH door.
J97 Rear harness; approx. 175 mm from connector H43-2 branching point towards rear LH door.
J98 Rear harness; approx. 180 mm from connector H43-2 branching point towards front LH door.
J107 Rear harness; approx. 100 mm from connector H10-1.
J130 Driver's door; approx. 90 mm from door mirror branching point towards central lock.
J131 Passenger door; approx. 90 mm from door mirror branching point towards central lock.
J132 Boot lid/tailgate; approx. 30 mm from central lock branching point towards licence plate lighting.
J141 Instrument harness; approx. 60 mm from
LHD dashboard LH loudspeaker branching point towards main fuse board.
J141 Instrument harness; approx. 180 mm from
RHD MIU (20-pin connector) branching point towards DICE.
J142 Instrument harness; approx. 30 mm from
LHD DICE branching point towards steering wheel switch.
J142 Instrument harness; approx. 105 mm from
RHD grounding point G42 branching point towards DICE.

Grounding points
G3 In luggage compartment under LH light cluster.
G5 Under LH corner of rear seat.
G24 Behind seat member under RH seat.
G30 On LH structural member behind headlamp.
G31 On RH structural member behind headlamp.
G33 In cabin under left-hand A pillar.
G40 In cabin on LH side of knee member.
G41P LH ground screw on centre of knee member (in cabin).
G42 In cabin on RH Side of knee member.
