TCS Off Warning Lamp Constantly on

Fault Systems
TCS OFF warning lamp constantly on. No DTCs are set.

Conditions
^ Shorting to ground in the lead between pin 20 of the TC/ABS control module and pin 20 of the main instrument unit (K20).
^ Short-circuit contact strip faulty.

Diagnostic help
The TCS OFF warning lamp can be activated with the diagnostic tool.
^ Select "Activate"
^ Select "TCS OFF Lamp"
