Manual Transmission/Transaxle: Tools and Equipment





87 92 335 Locking Pin, Gear Position Adjustment




83 92 128 Locating Studs




83 94 850 Lifting Beam




83 95 212 Strap




87 92 616 Removing Tool, Drive Shaft




87 92 608 Lifting Tool MKM-886




83 95 162 Protective Collar




87 92 228 Holder, Transmission




87 92 343 Puller, Differential Bearing, 5th Gear Hub




89 96 084 Puller, Wheel Hub




87 92 566 Puller




87 91 410 Sleeve




87 92 129 Attaching Eye, Puller




87 91 287 Puller, 150 Mm




87 91 303 Arm, 150 Mm




83 90 114 Sleeve, 4th Pinion




87 92 103 Assembly Fixture, 1st-2nd Hub




87 91 295 Arm, 300 Mm




87 91 188 Support, Removel Of Pinion Shaft




87 91 972 Ring, Rear Pinion Bearing




87 92 202 Sleeve




87 91 204 Sleeve, Bearing Race




87 90 867 Assembly Ring, Bearing, Input Shaft




78 41 067 Sleeve, Bearing, Inner Driver




87 91 428 Driver




87 92 517 Support




87 92 582 Assembly Fixture




87 92 194 Kit, Dial Gauge




87 90 727 Mounting, Dial Gauge




87 92 137 Ground Bearing Race




87 92 095 Weight, Differential Bearing




87 92 053 Driver




87 92 061 Millimeter Wheel, 27 Mm




87 92 160 Puller Ring, 22 Teeth




87 92 004 Puller Ring, 21 Teeth




87 90 636 Fixture




87 92 152 Puller, Input Shaft




87 91 642 Basic Tool




87 91 121 Puller Ring




87 90 487 Sleeve, Differential Bearing




83 90 312 Drift, Race, Input Shaft




87 91 311 Sleeve, Cave Staff Bearing




87 91 220 Doff, Selector Rod Bush




83 90 122 Drift




87 90 800 Drift, Differential Bearing Seal




87 90 685 Assembly Tool, Selector Shaft Seal




87 91 709 Clamp




87 91 238 Drift Selector Rod Bush




87 92 590 Assembly Tool




87 92 350 Puller, Drive Staff Seal




87 91 683 Puller




83 90 148 Sleeve




87 91 659 Support




87 92 475 Press Sleeve




87 92 210 Support, Differential Bearing




87 92 483 Torque Wrench




83 94 801 Parent Fixture




87 92 632 Locking Pin, Gear Position Adjustment Long




87 92 640 Removal Tool




97 92 657 Fitting Tool Drive Shaft Seal
