Grounding Point G42

The following components are connected to grounding point G42 in the compartment on the RH side of the knee member:


B. From Rev 1:

G30 Grounding point in engine bay on side panel in front of LH wheel housing (RHD only)

Via crimp J42

10 Switch, lights
21 Relay, ignition switch
42 Level switch, brake fluid
242 Level switch, coolant
628 Control module, DICE

Via crimp J46 (LHD only)

19 Lamp, glove box lighting
353 Main unit, audio system
354 Amplifier, audio system
59RH Lamp, vanity mirror, RH
613FL Lamp, floor lighting, front LH
613FR Lamp, floor lighting, front RH
