Grounding Point G30

The following components are connected to grounding point G30 in the engine bay on the side plate in front of the left-hand wheel housing:

G40 Grounding point in compartment on LH-side of knee member (from Rev.1 LHD only)
G42 Grounding point in compartment on right- hand side of knee member (from Rev.1 on RHD)

Via crimp J2

63b Motor, pump, washer fluid, windscreen
66FL Motor, headlamp wiper, LH
85FL Lamp, fog light, LH
118FL Lamp, corner light, LH
119FL Lamp, side reversing light, LH
228b Relay, filament monitor (to Rev.1)
275 Siren, anti-theft alarm
280FL Motor, headlamp beam adjustment, LH
458 Pressure switch, vacuum
459 Motor, vacuum pump
547 Control module, ABS

Via crimp J3

11FL Lamp, main beam, LH
12FL Lamp, dipped beam, LH
13FL Lamp, parking light, front, LH
27FL Lamp, front direction indicator, LH
37LH Motor, radiator fan, LH
37RH Motor, radiator fan, RH
40LH Horn LH
40RH Horn RH
63a Motor, pump, washer fluid, headlamp wipers
81 Relay, radiator fan
195 Level switch, washer fluid
228b Relay, filament monitor (from Rev-1)
367 Resistor, 2-speed radiator fan
