Checking Relay to Secondary Air Injection Pump - II

Checking Relay To Secondary Air Injection Pump





- Connect test lamp 86 11 857 to pins 4 and 5 of the female connector.





- Activate SAI pump.





- The test lamp should light.

Is the function correct?

NO - Rectifying the Lead - II

YES - Changing Components
