C2484

C2415 RL solenoid valves faulty.
C2450 FL solenoid valves faulty.
C2455 FR solenoid valves faulty.
C2485 FR solenoid valves faulty.

Fault Symptoms
ABS warning light on. ABS not functioning.

Conditions
The valves are monitored continuously for circuit continuity and short-circuiting. The valve test starts when the ignition is switched on and the road speed is above 6 km/h.

Diagnostic help
The solenoid valves can be activated using the diagnostic tool.
^ Select: "Activate".
^ Select: "Valves"
Select the valve from the submenu. The selected valve will be activated at a frequency of 1 Hz for about 30 s. Replace the control module.
