Grounding Point G3

The following components are connected to grounding point G3 in the luggage compartment under the left-hand light cluster:

Via crimp J91

13RL Lamp, parking light, rear, LH
13RR Lamp, parking light, rear, RH
27RL Lamp, direction indicators, rear, LH
27RR Lamp, direction indicators, rear, RH
30RL Lamp, brake light, rear, LH
30RR Lamp, brake light, rear, RH
55 Lamp, luggage compartment lighting
355 CD changer

Via crimp J132 (boot lid), which is connected to crimp J91

15 Lamp, number plate lighting
32HL Lamp, reversing light, LH
32HR Lamp, reversing light, RH
33HL Lamp, rear fog light, LH
33HR Lamp, rear fog light, RH
56 Switch, luggage compartment lighting
622 Microswitch, luggage compartment lock
