Headlamp Wipers

Removal







1 Remove the direction indicators and headlamps.
2 Unplug the connector.
3 Remove the wiper arm and blade from the motor.
4 Remove the wiper motor retaining screws.
5 Remove the motor.

Refitting







1 Place the wiper motor in position and retit the retaining screws.
2 Plug in the connector.
3 Refit the wiper arm and blade on to the motor.
4 Fit the direction indicators and headlamps.
