Selector Lever Lighting

To remove





1. Remove the rim around the indicator display.
2. Remove the indicator display by carefully pressing in the catches.
3. Lift up the indicator display.
4. Lift up the green strip and remove the grid.
5. Remove the lamp with a pair of pliers.

To fit





1. Fit a new lamp.
2. Fit the grid under the green strip.
3. Fit the indicator display.
4. Fit the rim around the indicator display.
