Generator Not Charging

Fault symptoms
Generator not charging


Check
Check the following:












- The battery cable shoes are tight on the poles and that no oxide is present.
- The battery cables are tight where they connect with the car and that there is no oxide or other corrosion to cause bad contact.
- The generator connections are tight and there is no oxide or other corrosion to cause bad contact.
- The generator belt is in good condition and correctly tensioned.
