Checking the Fuse - I

Checking The Fuse







- Check fuse 32 in the dashboard's main fuse board.

Is the function correct?

NO - Continue With Checking The Fuse

YES - Checking the Operation of the Relay - I







- Replace the fuse.
- Remove the fuel pump relay.












- Connect a jumper lead between B+ and relay holder pin 2.







- Check fuse 32 in the dashboard's main fuse board.

Is the function correct?

NO - Continue With Checking The Fuse

YES - Final Check

Unplug the connector:
- H4-18
- Replace the fuse.

Did fuse 32 blow again?

NO - Changing Components - V

YES - Rectifying the Lead - X
