Interior Lighting Malfunctioning

Interior Lighting Malfunctioning:

Fault symptoms
Interior lighting malfunctioning

Diagnostic help
Check whether the glove box lighting is working. If not: Check fuse 4 in the cabin.

The following values can be read with the diagnostic tool:
- Reading lights, output

The following functions can be activated with the diagnostic tool:
- Reading lights

Check the wiring harness
Jiggle the wiring harness in several places and in various directions to detect intermittent open circuits and short circuits in the wiring harness. Watch the multimeter, diagnostic tool and test lamp during the check.
