Home >> Saab >> 1999 >> 9-3 Convertible (9400) L4-2.0L Turbo (B204) >> Repair and Diagnosis >> Heating and Air Conditioning >> Blower Motor >> Testing and Inspection >> Fault Diagnosis, Fault Symptoms, ACC

Fault Diagnosis, Fault Symptoms, ACC




Ventilation Fan ACC Not Functioning:






Fault symptom
Ventilation fan ACC not functioning

Diagnostic procedure
Ventilation fan shorted to ground.
Ventilation fan open circuit or shorted to B+.
