P1628

Battery voltage too high or too low/Battery voltage +30 input to control module faulty







Fault symptoms
Faulty battery voltage usually causes problems with other system functions, which is why DTCs are often generate together with other DTCs.

Conditions
Voltage greater than 16 Volts (irrelevant of time) or less than 10 Volts for at least 3 seconds after start.
